Technical parameters:

voltage:  AC110-240 - v, 50 to 60 hz

Total power: 365 w

Bulb: Philips 330 w

Color temperature: 8000 k

Channel: 18 standard DMX control channel

The lamp body size: 396 * 390 * 390 (mm)

Aviation carton size: 470 * 470 * 470 (mm)

18 kg gross weight:

Performance characteristics

Stroboscopic: monolithic, 0.3-13 times/SEC adjustable ultra-high speed stroboscopic effect.

Prism: eight prism, a reversible variable rotation effect.

Beam Angle: 0 ° - 4 °

Optical system: adopt efficient quartz reflective bowl, all coated antireflection coating.

Focus: linear zoom lens, near and far clear can adjust.

Color plate: seven color + white light, the bidirectional variable speed rotation, the rainbow effect, panchromatic and half color walk two modes switching effect.

Pattern plate: 7 + white light design, can both positive and negative rotate speed variable jitter, water effect.

Protection: two convection fan cooling, internal optimization of wind path design, all intelligent temperature overheating and anti-interference electronic circuit protection, heat dissipation fully reliable.

Safety standard: in accordance with the CE standard and GB7000.15-2000 standard, IP20 protection level of protection, the power cord accord with the standard CE20/22.

Shell: the streamlined ABS flame retardant, high temperature resistant engineering plastics.

540 degrees in X axis: 8/16 bit resolution, built-in photoelectric automatic error correction function.

Y: 270 degrees, 8/16 bit resolution, built-in photoelectric automatic error correction function.
