Technical parameters:

Voltage: AC110-220 - v / 50 hz AC110V 60 hz (on-demand customized)

Light source: pins bubble MSD700W

Channel mode: 19 international standard DMX512 channel

Horizontal: 540 ° or 630 ° (16 bit precision scan) vertical scanning: 265 ° (16 bit precision scan)

CMY mixing color system color reel evenly: eight color + white light plug type, with two-way rotary rainbow effect with up to 30 default CMY and color plate melange effect

Color pattern plate rotating macro asynchronous operation: 6 the rotation of the plug type pattern piece + white round, with color pattern jitter pluggable type, design system, convenient change color

Pattern piece of prism plate: rotating prism 3 can be positive and negative direction of rotation

Stroboscopic: double pole stroboscopic frequency up to 13 times per second, and can choose random stroboscopic and pulse frequency flash

Linear dimming dimming: 0% ~ 100%

Linear atomization atomization: 0% ~ 100%

Focusing focus: according to the distance

Net weight: 33 kg

37 kg gross weight:

The lamp body size: 396 * 390 * 630 mm

Carton size: 515 * 440 * 785 mm
